With an extra-large cargo box and a host of ergonomic features, it is the best travel companion to carry your little ones through life's little adventures.

  • Extra-large Cargo Box
  • EV-style Sidelights
  • 960 Wh Portable Battery
  • Gates CDX Carbon Belt
  • Enviolo Stepless Shifting Hub
  • Mid-drive Motor
  • Versatile Cargo Functions
  • Comfortable Set-up

One size for riders of 160 ~ 195 cm (5'5'' ~ 6'5'')

Shipping starts in 3 working days from the Netherlands.
Available for DE, NL, BE, and LU only.

Electronics

  • Motor

    Bafang M600 Cargo (250W Power, 100 Nm Max. Torque)

  • Sensor

    Integrated Torque Sensor for the Mid-drive Motor

  • Controller

    Integrated Controller of the Mid-drive Motor

  • Display

    TFT LCD Color Display

  • Battery

    960Wh (48V, 20Ah) Lithium-ion Battery with LG Cells

  • Lights

    StVZO-compliant

Performance

  • Top Speed

    25 km/h*

    *The motor will stop giving assist at the stated top speed. You can still ride beyond the stated top speed with pure muscle power. This limit is set in accordance with local regulations.

  • Range

    Up to 90 km*

    *Results of single battery charge range tests with an empty cargo box. Actual performance will vary depending on load, PAS levels, temperature, road conditions, rider's weight, etc.

  • Climbing Ability

    Suitable for Climbing Slopes*

    *The actual performance would depend on the rider's physical strength.

Component

  • Frame

    6061 Aluminium Frame

  • Crankset

    Aluminium Alloy Crankset

  • Wheels

    6061 Aluminium Rims

  • Rear Derailleur

    Enviolo Stepless Shifting Hub

  • Drivetrain

    Gates CDX Carbon Belt

  • Front Fork

    SR SUNTOUR Suspension Front Fork

  • Tires

    SCHWALBE 20''*2.15/26''*2.15 Puncture-proof Tires

  • Brake

    Tektro Four-piston Hydraulic Disc Brakes

  • Bottom Bracket

    Fully-concealed Bottom Bracket

  • Saddle

    Selle Royal Saddle

  • Weight*

    Net weight: 56 kg (excluding all accessories)
    Full weight: 58 kg (including all accessories)
    Permissible Max. Weight: 250 kg



    *All stated weight numbers have a +/- 3%-5% tolerance. Net weight includes the battery but excludes all accessories. Full weight includes the battery and all accessories.

*Specifications are subject to change without notice. In case of unexpected supply-side impacts, we will offer components of equivalent or better capabilities.

Geometry

One Size (mm)SYMBOL
Effective top tubeA653.5
Seat tube lengthB485
Head tubeC85
Steering angleD64.4
Seat tube angleE69.1
ChainstayF436
WheelbaseG2030
StandoverH443





TENWAYS CARGO ONE

£4,999.00Price
Excluding Sales Tax
