specifications
Frame
META SX, 165 mm travel
29''-27.5'', Alloy 6066, triple butted tubes, T4, T6.
Shock
FOX Float X2 Factory
230 x 65 mm, 2-pos adjustment, HSC, LSC, HSR, LSR
Fork
FOX 38 Factory 2027, 170 mm travel
29'', Grip X2, HSC, LSC, HSR, LSR, Boost (15 x 110), 44 mm offset, 2 Tokens
Headset
ACROS ZS56/ZS56
Alloy cups, sealed bearings
Stem
RIDE ALPHA 40
40 mm extension, 31.8 mm
Handlebar
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M - RIDE ALPHA R27 800 on L / XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M - 31.8 mm, 800 mm width, 35 mm rise, Alloy 6061 on L / XL
Grips
ODI Longneck V2.1
Black clamp
Brakes
SHIMANO XT, 4 pistons, resin pads
Rotors : SHIMANO MT905 203 mm, 6-bolts
Shifters
SRAM Eagle 90
12s
Chain guide
RIDE ALPHA
32t-34t
Rear derailleur
SRAM Eagle 90
12s
Bottom bracket
SRAM DUB92
MTB Wide, Pressfit
Crankset
SRAM X0 T-Type, 165 mm crank arms
Chainring : SRAM X0 T-Type, 32t
Chain
SRAM GX T-Type
12s
Cassette
SRAM XS 1275
12s, 10-52t
Rims
DT SWISS EX1700
Rear : 27.5'', 32h, 28 mm inner width - Front : 29'', 32h, 28 mm inner width
Hubs
DT SWISS 350
Rear : 32h, sealed bearings, 12 x 148 mm, SRAM XD - Front : 32h, sealed bearings, 15 x 110 mm
Spokes/nipples
DT SWISS Competition
J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black
Tyres
Rear : MAXXIS DHR II - Front : MAXXIS Assegai
Rear : 27.5"x2.5" WT, 3C MaxxTerra, New EXO+, Tubeless Ready - Front : 29"x2.5" WT, 3C MaxxGrip, New EXO+, Tubeless Ready
Seat post
ONE UP V3
34.9 mm, travel: 150 mm on S, 180 mm on M and 210 mm on L/XL, I-Spec EV SouthPaw alloy remote
Saddle
WTB Solano
Crmo rails, 142 x 240 mm
Weight
16,9 kg / 37.25 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Pedals included
No
Colour
Pure Black
Shiny Finish
Accessories
Down tube protector, chainstay protector, seatstay protector, pick up pad, fork fender, FIDLOCK base
Technical informations
Bicycle type
Enduro / Freeride
Frame material
AL 6066 T4, T6
Frame weight
4,08 kg / 8,99 lb
Rear travel
165mm
Shock length/stroke
230x65mm
Recommended SAG
27-30% / 18-20mm
Piggy back shock compatible
Yes
Shock bushings
20x10mm / no bushing needed on clevis
Recommended/max. fork height
586mm / 598mm
Headset type
ZS56 / ZS56
ICR compatible
Yes
Wheels size
29’’ - 27.5’’
Max. rear tyre dimension - ETRTO
65mm - Ø584mm
rear brake mounting type
Postmount 200mm
Rear brake rotor max. size
223mm
Seatpost/seat clamp diameter
34,9mm / 38,5mm
Seatpost insertion max.
S : 230mm / M : 270mm / L : 290mm / XL : 310mm
Bottom bracket type
Press Fit BB 92mm
Chain guide
ISCG 05 lower - Custom upper guide
Recommended/max. chainring teeth
32T / 34T
Chain Line
55
Rear Hub dimension
148x12mm
Rear Axle dimension
UDH standard, 180mm, M12, P1.0mm
UDH hanger
Yes
shock anchor adjustment
No
