specifications
Frame
META POWER SX V4, 165 mm travel
29"-27.5", Alloy 6066, triple butted tubes, T4, T6. Enduro bearings
Motor
SHIMANO DU-EP800
Max. torque: 85N.m, 250W
Battery
SHIMANO BT-E8036
630Wh internal battery
SHIMANO Europlug (CEE 7/7 norm) battery charger
(a plug adapter is necessary for customers living in countries using different standards)
Display
SHIMANO SC-EM800
LCD colored display featuring: Clock, Assist mode display, Battery charge level, Current Speed, Maximum speed, Average speed, Trip distance, Trip time, Estimated range, Range overview, Cadence, Human output power (as scale indicator), Calorie setting, Maintenance alert, Bluetooth LE connection (for E-Tube Project communication)
Shock
ROCKSHOX Super Deluxe Ultimate
230 x 65 mm, RC2T damper, DebonAir, LSC, HSC, rebound, 2-position (open/firm), 1 Token neg. 0 Token pos.
Fork
ROCKSHOX Zeb Ultimate, 170 mm travel
29", Charger 2.1 RC2 damper, Debonair, LSC, HSC, rebound, Boost (15 x 110 mm), 44 mm offset, 1 Token
Headset
ACROS ZS56 / ZS66
Alloy cups, sealed bearings
Stem
RIDE ALPHA Freeride 40
40 mm extension, 31,8 mm
Handlebar
RIDE ALPHA R20 POWER on S - RIDE ALPHA R27 POWER on M / L / XL
Internal Di2 cable routing - 31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
Grips
ODI Elite Motion
Soft pro compound, single clamp, black
Brakes
TRP DH-R Evo, 4 pistons, resin pads
Rotors : TRP R1 220mm, 6 holes, 2.3 mm thickness
Shifters
SRAM GX Eagle
12s, Single Click
Chain guide
RIDE ALPHA EP8
32-34t
Rear derailleur
SRAM GX Eagle
12s
Crankset
SHIMANO FC-EM900, 160 mm crank arms
Chainring : E13 E*Spec Plus 34t, Narrow-Wide, direct mount
Chain
SRAM GX Eagle
12s
Cassette
SRAM XG-1275 Eagle
12s, 10-52t
Rims
Rear: DT SWISS HX1700 Spline - Front: DT SWISS HX1700 Spline
Rear: 27.5'', 28h, 30 mm inner width - Front: 29'', 28h, 30 mm inner width
Hubs
Rear: DT SWISS 350 - Front: DT SWISS 350
Rear: 28h, 12 x 148 mm, sealed bearings, 24t, Sram XD, e-bike specific - Front: 28h, 15 x 110 mm, sealed bearings
Spokes/nipples
DT SWISS Hybrid 1
Straightpull, 2.34/2.0mm, double butted, stainless, with ProLock, black
Tyres
Rear: SCHWALBE Big Betty - Front: SCHWALBE Magic Mary
Rear: 27.5"x2.4", Super Trail, Addix Soft, Tubeless Easy - Front: 29"x2.4", Super Trail, Addix Soft, Tubeless Easy
Seat post
KS Lev Integra
31.6 mm, travel: 125 mm on S, 175 mm on M/L & 200 mm on XL, SouthPaw alloy remote
Saddle
FIZIK Terra Aidon X3
145 mm width, Kium Mobius rails
Weight
24,8 kg / 54.67 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Pedals included
RIDE ALPHA CNC

Colour
Silver
Matte Finish
Accessories
Motor protector, chainstay protector, seatstay protector, Mudguard
Technical informations
Bicycle type
E-bike - Enduro / Freeride
Frame material
AL 6066 T4, T6
Frame weight
4,1 kg / 9.03 lb
Rear travel
165mm
Shock length/stroke
230x65mm
Recommended SAG
26-30% / 17-20mm
Piggy back shock compatible
Yes
Shock bushings
20x10mm / no bushing needed on clevis
Recommended/max. fork height
583mm / 593mm
Headset type
ZS56 / ZS66
ICR compatible
Yes
Wheels size
29’’ - 27.5’’
Max. rear tyre dimension - ETRTO
65mm - Ø584mm
rear brake mounting type
Postmount 160mm
Rear brake rotor max. size
220mm
Seatpost/seat clamp diameter
31,6mm / 34,9mm
Seatpost insertion max.
S : 220mm / M : 240mm / L : 270mm / XL : 280mm
Motor Crankarms interface
SHIMANO EP8
Chain guide
Custom upper guide
Recommended/max. chainring teeth
34T / 36T
Chain line
53
Rear Hub dimension
148x12mm
Rear Axle dimension
Maxle standard, 180mm, M12, P1.75mm
UDH hanger
No
shock anchor adjustment
2 positions
