specifications
Frame
META POWER SX AVINOX, 160 mm travel
29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings
Motor
AVINOX M2S
150 Nm peak torque with a 1,300 W boost mode, and 130 Nm / 1300 W in normal operation
Battery
AVINOX
600 Wh on S, 800 Wh on M / L / XL, Fully integrated main battery
AVINOX 508w Fast Battery charger
Display
AVINOX DP100 : Integrated and colored touchscreen providing a large range of information : speed, ride mode, battery range, charge level, fitness data, elevation gain, altitude and many more. It also features a USB-C port, GPS sensor, barometer, compass, 4G connection and even a theft alarm system.

AVINOX BD100, ON/OFF switch, assist mode level, battery charge level
Switch: AVINOX BC100, mode switch, walk assist, light switch
Shock
FOX Float X Factory
230 x 60 mm, 2-postion (open/firm) lever, HSC, LSC, HSR, LSR, 0.4ci Spacers
Fork
FOX 36 Factory 160 mm
29", Grip X2 damper, HSR, LSR, HSC, LSC, Boost (15 x 110 mm), 44 mm offset
Headset
ACROS ZS56 / ZS66
Alloy cups, stainless steel & sealed bearings
Stem
RIDE ALPHA 40
40 mm extension, 31.8 mm
Handlebar
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
Grips
ODI LONGNECK V2.1
Soft compound, single clamp, black
Brakes
SHIMANO XT, 4 pistons
Rotors: GALFER SHARK, 6-bolt, 203 mm
Shifters
SRAM AXS POD
12s
Chain guide
RIDE ALPHA
32-34t
Rear derailleur
SRAM GX EAGLE T-TYPE
12s
Crankset
E13 HELIX RACE, 155 mm crank arms, Bosch
Chainring: SRAM CR T-TYPE, 34t, BCD 104
Chain
SRAM GX EAGLE T-TYPE
12s, Flat Top
Cassette
SRAM X0 EAGLE T-TYPE
12s, 10-52t
Rims
DT SWISS HX1700
Rear: 27.5'', 28h, 30 mm inner width - Front: 29'', 28h, 30 mm inner width
Hubs
DT SWISS 350 Hybrid
Rear: 28h, sealed bearings, 12 x 148 mm, DEG DF, SRAM XD - Front: 28h, sealed bearings, 15 x 110 mm
Spokes/nipples
DT SWISS Hybrid 1
Straightpull, 2.34/2.0mm, double butted, stainless, with ProLock, black
Tyres
Rear: MAXXIS MINION DHRII 27.5'' - Front: MAXXIS MINION DHRII 29'
Rear: 27.5x2.50WT 3C MaxxTerra / EXO+ Casing / TR - Front: 29x2.50WT 3C MaxxTerra / EXO+ Casing / TR
Seat post
ONE UP V3
34.9 mm, 150 mm on S, 180 mm on M and 210 mm on L/XL
Saddle
WTB SOLANO
142 x 240 mm, Medium
Weight
24,1 kg / 53.13 lbs
Minimum weight for M size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Pedals included
CRANKBROTHERS Stamp 1
Colour
Pure Black
Shiny Finish
Accessories
RideWrap Lotus Pro™ protection film applied, motor protector, chain stay protector, seat stay protector, FIDLOCK base, fork fender, CRANKBROTHERS STAMP 1 pedals

Technical informations
Bicycle type
E-bike - Enduro / Freeride
Frame material
AL 6066 T6
Frame weight
4,795 kg / 10,57 lb
Rear travel
160mm
Shock length/stroke
230x60mm
Recommended SAG
29-32% / 17,5-19mm
Piggy back shock compatible
Yes
Shock bushings
20x10mm / no bushing needed on clevis
Recommended/max. fork height
576mm / 586mm
Headset type
ZS56 / ZS66
ICR compatible
Yes
Wheels size
29’’ - 27.5’’
Max. rear tyre dimension - ETRTO
65mm - Ø584mm
rear brake mounting type
Postmount 200mm
Rear brake rotor max. size
223mm
Seatpost/seat clamp diameter
34,9mm / 38,5mm
Seatpost insertion max.
S : 180mm / M : 220mm / L : 240mm / XL : 260mm
Motor Crankarms interface
AVINOX
Chain guide
Custom upper guide
Recommended/max. chainring teeth
34T / 36T
Chain line
55
Rear Hub dimension
148x12mm
Rear Axle dimension
UDH standard, 180mm, M12, P1.0mm
UDH hanger
yes
