specifications
Frame
META POWER SX 800, 180 mm travel
29''-27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings
Motor
BOSCH Performance Line CX Gen5
120 Nm
Battery
BOSCH Powertube 800
Fully integrated main battery, 800 Wh
BOSCH 4A Battery Charger. Compact size & lightweight
Display
BOSCH Kiox 400C : Integrated and colored display providing a large range of information : speed, ride mode, battery range, charge level, fitness data, elevation gain, altitude and even navigation.
BOSCH System Controller, ON/OFF switch, assist mode level, battery charge level
Switch: BOSCH Mini Remote, mode switch, walk assist, light switch
Shock
FOX Float X2 Factory
230 x 65 mm, 2-postion (open/firm) lever, HSC, LSC, HSR, LSR
Fork
FOX 38 Factory E-Bike, 180 mm
29", Grip X2 damper, HSR, LSR, HSC, LSC, Boost (15 x 110 mm), 44 mm offset, 3 spacers
Headset
ACROS ZS56/ZS66
Alloy cups, stainless steel & sealed bearings
Stem
RIDE ALPHA 40
40 mm extension, 31.8 mm
Handlebar
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
Grips
ODI Longneck 2.1
Soft compound, single clamp, black
Brakes
TRP DH-R EVO PRO, 4 pistons, resin pads
Rear rotor: TRP RS05 203 mm - Front rotor: TRP RS05 220 mm
6-bolt, 2.3 mm width
Shifters
SRAM Eagle 90
12s
Chain guide
RIDE ALPHA
32-34t
Rear derailleur
SRAM Eagle 90
12s
Crankset
E13 Helix Core E*Spec, 155 mm crank arms, Bosch
Chainring: SRAM XX T-Type E-MTB, 34t for Bosch system, direct mount
Chain
SRAM GX T-Type
12s, Flattop
Cassette
SRAM GX T-Type
12s, 10-52t
Rims
DT SWISS FR541
Rear: 27.5'', 28h, 30 mm inner width - Front: 29'', 28h, 30 mm inner width
Hubs
Rear: DT SWISS 370 Hybrid - Front: DT SWISS 370
Rear: 28h, sealed bearings, 12 x 148 mm, 24t, SRAM XD - Front: 28h, sealed bearings, 15 x 110 mm
Spokes/nipples
Included with wheelset
Tyres
Rear: MAXXIS Minion DHRII 27.5'' - Front: MAXXIS ASSEGAI 29''
Rear: 27.5x2.50 WT, 3C MaxxTerra, Double Down, TR - Front: 29x2.50 WT, 3C MaxxGrip, New EXO+, TR
Seat post
ONE UP V3
31.6 mm, 150 mm on S, 180 mm on M, 210 mm on L/XL
Saddle
FIZIK Terra Aidon X5
145 mm width, Kium Mobius rails
Weight
25,5 kg / 56.22 lbs
Minimum weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Pedals included
CRANKBROTHERS Stamp 1
Colour
Pure Black
Shiny Finish
Accessories
RideWrap Lotus Pro™ protection film applied, motor protector, chain stay protector, seat stay protector, FIDLOCK base, fork fender, CRANKBROTHERS STAMP 1 pedals
 Technical informations
Bicycle type
E-bike - Enduro / Aventure
Frame material
AL 6066 T6
Frame weight
5,86 kg / 12.91 lb
Rear travel
180mm
Shock length/stroke
230x65mm
Recommended SAG
28-31% / 18-20mm
Piggy back shock compatible
Yes
Shock bushings
20x10mm / no bushing needed on clevis
Recommended/max. fork height
588mm / 598mm
Headset type
ZS56 / ZS66
ICR compatible
Yes
Wheels size
29’’ - 27.5’’
Max. rear tyre dimension - ETRTO
65mm - Ø584mm
rear brake mounting type
Postmount 200mm
Rear brake rotor max. size
223mm
Seatpost/seat clamp diameter
34,9mm / 38,5mm
Seatpost insertion max.
S : 180mm / M : 220mm / L : 240mm / XL : 260mm
Motor Crankarms interface
BOSCH CX Gen5
Chain guide
Custom upper guide
Recommended/max. chainring teeth
34T / 34T
Chain line
55
Rear Hub dimension
148x12mm
Rear Axle dimension
UDH standard, 180mm, M12, P1.0mm
UDH hanger
yes
