specifications
Frame
FRS, 200 mm travel
27.5'', Alloy 6069, triple butted tubes, T4, T6. Enduro bearings
Shock
FOX Float X2 Factory
250 x 75 mm, 2-postion (open/firm) lever, HSC, LSC, HSR, LSR, spacers 0.3 x2
Fork
FOX 40 Factory, 200 mm
27,5", Grip X2, HSR, LSR, HSC, LSC, Boost (15 x 110 mm), 48 mm offset
Headset
ACROS ZS44 / ZS56
Alloy cups, sealed bearings
Stem
RIDE ALPHA DH 40
40 mm extension, direct mount, 31.8 mm
Handlebar
RIDE ALPHA R27
31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on S / M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
Grips
ODI Longneck V2.1
132 mm, Single clamp, black
Brakes
TRP DH-R EVO PRO, 4 pistons, resin pads
Rotors: TRP R2 223 / 203 mm, 6-bolt, 2.3 mm thickness
Shifters
SRAM GX DH
7s
Chain guide
E13 Vario
34-36t
Rear derailleur
SRAM GX DH
7s
Bottom bracket
SRAM BB107
BB107
Crankset
SRAM Descendant DH, 165 mm crank arms, DUB
Chainring: SRAM Descendant DH, 34t
Chain
KMC X11EL
11s, Black
Cassette
SRAM PG-720
7s, 11-25t
Rims
Rear: DT SWISS FR541 - Front: DT SWISS FR571
27.5'', 32h, 30 mm inner width
Hubs
DT SWISS 350
Rear: 32h, sealed bearings, 12 x 150 mm, 18t ratchet, SHIMANO Hyperglide - Front: 32h, sealed bearings, 20 x 110 mm
Spokes/nipples
Included with Wheelset
Tyres
Rear: MAXXIS Minion DHRII - Front: MAXXIS Assegai
Rear: 27.5x2.50WT 3C MaxxTerra / DH Casing / TR - Front: 27.5x2.50WT 3C MaxxGrip / DH Casing / TR
Seat post
RIDE ALPHA
31.6 mm, 250 mm length
Saddle
FIZIK Gravita Alpaca X5
130 mm width, S-Alloy rails, Team edition
Weight
17,3 kg / 38.13 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Pedals included
No
Colour
Pure White
Shiny Finish
Accessories
Down tube protector, chainstay protector, seatstay protector, shuttle pad, fork bumpers

*Please note that bike specs are subject to change without prior notice.
Technical informations
Bicycle type
Downhill / Freeride
Frame material
AL 6069 T4, T6
Frame weight
4,22 kg / 9,3 lb
Rear travel
200mm
Shock length/stroke
250x75mm
Recommended SAG
28-32% / 21-24mm
Piggy back shock compatible
Yes
Shock bushings
20x8mm / 30x10mm
Recommended/max. fork height
581mm / 595mm
Headset type
ZS44 / ZS56
ICR compatible
No
Wheels size
27.5’’ - 27.5’’
Max. rear tyre dimension - ETRTO
65mm - Ø584mm
rear brake mounting type
Postmount 200mm
Rear brake rotor max. size
203mm
Seatpost/seat clamp diameter
31,6mm / 34,9mm
Seatpost insertion max.
125mm
Bottom bracket type
Press Fit BB 107mm
Chain guide
ISCG 05
Recommended/max. chainring teeth
34T / 36T
Chain line
56,5
Rear Hub dimension
150x12mm
Rear Axle dimension
Maxle standard, 180mm, M12, P1.75mm
UDH hanger
No
shock anchor adjustment
2 positions
