specifications
Frame
2025 CLASH, 170 mm travel
27.5'', Alloy 6066, triple butted tubes, T4, T6. Bolu bearings
Shock
FOX DHX Factory
230 x 6 5mm, 2-pos lever, rebound, Spring rates : 400lbs on S, 450lbs on M, 500lbs on L, 550lbs on XL.
Fork
FOX 38 Factory, 180 mm
27.5", Grip X2, HSC, LSC, HSR, LSR, Boost (15 x 110), 37 mm offset, 0 Token
Headset
ACROS ZS44/ZS56
Alloy cups, sealed bearings
Stem
RIDE ALPHA 40
40 mm extension, 31.8 mm
Handlebar
RIDE ALPHA R20 760 on S - RIDE ALPHA R27 780 on M / L - RIDE ALPHA R27 800 on XL
31.8 mm, 760 mm width, 20 mm rise, Alloy 6061 on S - 31.8 mm, 780 mm width, 27 mm rise, Alloy 6061 on M / L - 31.8 mm, 800 mm width, 27 mm rise, Alloy 6061 on XL
Grips
ODI Longneck V2.1
Ultra-soft compound, single clamp, black
Brakes
TRP DHR EVO PRO, 4 pistons, resin pads
Rotors: TRP R2 203 mm, 6-bolts
Shifters
SHIMANO XT
12s
Rear derailleur
SHIMANO XT
12s
Bottom bracket
SHIMANO MT800
Pressfit
Crankset
SHIMANO XT, 165 mm crank arms
Chainring: SHIMANO XT, 32t
Chain
SHIMANO XT
12s
Cassette
SHIMANO XT
12s, 10-51t
Rims
DT SWISS F1900 Classic
27.5'', 32h, 30 mm inner width
Hubs
DT SWISS 370 Classic LN
Rear: 32h, sealed bearings, 12 x 148 mm, SHIMANO Microspline - Front: 32h, sealed bearings, 15 x 110 mm
Spokes/nipples
DT SWISS Competition
J-Bend, 2.0-1.8-2.0mm, double butted, stainless, with Nylok, black
Tyres
Rear: MAXXIS Minion DHR II - Front: MAXXIS Assegai
Rear: 27.5''x2.5'', 3C MaxxTerra, Nexo+ - Front: 27.5''x2.5'', 3C MaxxGrip, Nexo +
Seat post
KS Lev Integra
34.9 mm, 125 mm on S, 175 mm on M, 200 mm on L
Saddle
FIZIK Terra Ridon X5
145 mm, Alloy rails
Weight
15,8 kg / 34.83 lb
Average weight for S size, without pedals. Weight may differ slightly due to manufacturing tolerances.
Pedals included
No
Colour
Pure White
Shiny Finish
Accessories
Down tube protector, chainstay protector, seatstay protector, shuttle pad, Fork mud guard
Technical informations
Bicycle type
Enduro / Freeride
Frame material
AL 6069 T4, T6
Frame weight
4,1 kg / 9.03 lb
Rear travel
155mm / 170mm
Shock length/stroke
230x65mm
Recommended SAG
26-30% / 17-20mm
Piggy back shock compatible
Yes
Shock bushings
20x8mm / 30x10mm
Recommended/max. fork height
572mm / 586mm
Headset type
ZS44 / ZS56
ICR compatible
No
Wheels size
27.5’’ - 27.5’’
Max. rear tyre dimension - ETRTO
65mm - Ø584mm
rear brake mounting type
Postmount 200mm
Rear brake rotor max. size
223mm
Seatpost/seat clamp diameter
34,9mm / 38,5mm
Seatpost insertion max.
S : 250mm / M-L-XL : 275mm
Bottom bracket type
Press Fit BB 92mm
Chain guide
ISCG 05
Recommended/max. chainring teeth
32T / 34T
Chain line
55
Rear Hub dimension
148x12mm
Rear Axle dimension
Maxle standard, 180mm, M12, P1.75mm
UDH hanger
No
shock anchor adjustment
2 positions
