Electronics
Motor
Mivice M070 Rear Hub Motor (250W Power, 40 Nm Max. Torque)
Sensor
Mivice S200 Torque Sensor
Display
Compact OLED Display
Battery
36V, 10Ah Lithium-ion Battery with LG Cells
Controller
Mivice C201 Controller
Lights
StVZO-compliant
Performance
Top Speed
25 km/h*
*The motor will stop giving assist at the stated top speed. You can still ride beyond the stated top speed with pure muscle power. This limit is set in accordance with local regulations.
Range
Up to 100 km*
*Actual performance will vary depending on temperature, road conditions, rider's weight, etc.
Climbing Ability
Suitable for flat roads*
*The actual performance would depend on the rider's physical strength.
Component
Frame
6061 Aluminium Frame
Front Fork
6061 Aluminium Front Fork
Drivetrain
Single-speed Drivetrain
Gates CDN Carbon Belt
Crankset
Gates CDX Crankset
Tires
CST Puncture-proof 700C-size Tires
Bottom Bracket
Fully-concealed Bottom Bracket
Wheels
700C Aluminium Rims
Brake
TEKTRO Hydraulic Disc Brakes
Weight*
Net weight: 16 kg (excluding all accessories)
Full weight: 18 kg (including all accessories)
Permissible Max. Weight: 140 kg
*All stated weight numbers have a +/- 3%-5% tolerance. Net weight includes the battery but excludes all accessories. Full weight includes the battery and all accessories.
*Specifications are subject to change without notice. In case of unexpected supply-side impacts, we will offer components of equivalent or better capabilities.
Geometry
SIZE (mm)
SYMBOL
S
M
L
XL
Top tube
A
598
605
615
630
Seat tube
B
460
500
540
580
Head tube
C
140
140
140
140
Head tube angle
D
71.5
71.5
71.5
71.5
Seat tube angle
E
73.5
73.5
73.5
73.5
Chainstay
F
457
457
457
457
Wheelbase
G
1099
1105.3
1115.7
1130.7
Standover
H
787
805
823
841
